CAT'26 QUANT CHEATSHEET
Every coordinate geometry formula you need for CAT 2026 — on one page.
Coordinate Geometry on CAT is algebra wearing a graph — every question is really about distances, ratios, and equations of lines, just expressed through x-y points instead of raw numbers. Once you have the distance, section and slope formulas down, most of the topic becomes substitution: build a line’s equation, check a distance, or read a circle’s centre straight off its equation. This sheet lays out every formula you need for the CAT quant section: distance, section and midpoint formulas, every standard form of a line’s equation, parallel and perpendicular conditions, point-to-line and line-to-line distances, triangle area and collinearity, circles, family of lines, and locus and reflection, each with a worked example in real numbers. Keep it open while you practise, and after a mock check where you stand on the CAT score predictor to see which idea is costing you marks.
Coordinate Geometry: every formula you need
1Distance Formula
The straight-line distance between any two points.
d = √[(x2−x1)2+(y2−y1)2]
Example: (1,2) and (4,6) → √(9+16) = √25 = 5.
CAT Hack: If the answer needs to be an integer, look for a 3-4-5-style right-triangle gap between the coordinates.
2Section Formula
The point that divides a segment in a given ratio.
internal m:n → (mx2+nx1)/(m+n), (my2+ny1)/(m+n)
Example: A(1,1), B(7,7), ratio 1:2 → ((7+2)/3, (7+2)/3) = (3, 3).
Common Mistake: External division flips a sign: use (m−n) in the denominator instead of (m+n).
3Midpoint & Centroid
The balance point of a segment, and of a triangle's three vertices.
Midpoint = (x1+x2)/2, (y1+y2)/2 | Centroid = average of all 3 vertices
Example: triangle (0,0), (6,0), (3,9) → centroid = (9/3, 9/3) = (3, 3).
4Slope of a Line
How steep a line is, from any two points on it.
m = (y2−y1) / (x2−x1)
Example: (2,3) and (5,9) → (9−3)/(5−2) = 6/3 = 2.
CAT Insight: A vertical line has an undefined slope — the denominator becomes zero.
5Equation of a Line: Slope Forms
Build a line's equation from its slope and one known point.
slope-intercept: y=mx+c | point-slope: y−y1=m(x−x1)
Example: slope 2 through (1,3) → y−3=2(x−1) → y = 2x+1.
6Equation of a Line: Two-Point & Intercept Forms
Build a line's equation from two points, or from its axis intercepts.
two-point: (y−y1)/(y2−y1) = (x−x1)/(x2−x1) | intercept: x/a+y/b=1
Example: through (1,1) and (3,5) → slope=2 → y = 2x−1.
7Parallel & Perpendicular Lines
How the slopes of two lines relate depending on their orientation.
parallel: m1 = m2 | perpendicular: m1·m2 = −1
Example: slope 3 and slope −1/3 → product = −1 → perpendicular.
CAT Hack: Given one line's slope m, a perpendicular line's slope is always −1/m — flip and negate.
8Angle Between Two Lines
The acute angle formed where two lines cross.
tanθ = |(m1−m2) / (1+m1m2)|
Example: m1=1, m2=0 → tanθ=|(1−0)/(1+0)|=1 → θ=45°.
9Distance of a Point from a Line
The perpendicular distance from a point to a line Ax+By+C=0.
d = |Ax1+By1+C| / √(A2+B2)
Example: point (2,3), line 3x+4y−6=0 → |6+12−6|/5 = 12/5 = 2.4.
Common Mistake: Don't drop the absolute value — the raw numerator can come out negative before you take it.
10Distance Between Two Parallel Lines
Parallel lines share A and B, so only the constants differ.
d = |C1−C2| / √(A2+B2)
Example: 3x+4y−6=0 and 3x+4y+9=0 → |−6−9|/5 = 15/5 = 3.
11Area of a Triangle (Coordinates)
Compute a triangle's area directly from its three vertices.
Area = ½|x1(y2−y3)+x2(y3−y1)+x3(y1−y2)|
Example: (0,0), (6,0), (0,8) → ½|48| = 24.
CAT Favourite: This one formula handles both triangle area and collinearity checks — a genuine CAT favourite.
12Collinearity of Three Points
Three points lie on one line exactly when their triangle's area is zero.
points collinear ⇔ area of the triangle they form = 0
Example: (1,1), (2,2), (3,3) → area = ½|−1+4−3| = 0 → collinear.
13Equation of a Circle
The standard and general forms of a circle's equation.
(x−h)2+(y−k)2=r2 | general: x2+y2+2gx+2fy+c=0
Example: centre (2,3), radius 5 → (x−2)2+(y−3)2=25.
CAT Insight: From the general form, the centre is (−g, −f) and radius = √(g2+f2−c) — watch the sign flip on g and f.
14Family of Lines
A single equation that represents every line through a fixed intersection point.
L1 + λL2 = 0 passes through the intersection of L1=0 and L2=0
Example: (x+y−3)+λ(2x−y)=0 passes through the intersection of x+y=3 and 2x=y, for any λ.
CAT Hack: Use this to skip solving for the intersection point directly when a question only needs a line through it.
15Locus & Reflection
The path traced by points satisfying a condition, and mirrored points.
reflect about x-axis: (x,−y) | about y-axis: (−x,y) | about y=x: (y,x)
Example: reflect (3,4) about the x-axis → (3, −4).
CAT exam shortcuts, traps & revision
16
CAT Exam Shortcuts
- Distance = √[(x2−x1)2+(y2−y1)2]; midpoint = average of coordinates
- Parallel: m1=m2; perpendicular: m1m2=−1 (flip and negate)
- Point-to-line distance = |Ax+By+C| / √(A²+B²)
- Area of a triangle from coordinates also tests collinearity (area = 0)
- Circle general form: centre = (−g, −f), radius = √(g²+f²−c)
- Family of lines L1+λL2=0 skips solving for the intersection directly
17
Most Common CAT Traps
- Dropping the absolute value in the point-to-line distance formula.
- Using (m−n) instead of (m+n) in the section formula for internal division, or vice versa for external.
- Getting the perpendicular-slope condition backwards (it's a product of −1, not equal slopes).
- Reading the centre straight off the general circle equation as (g, f) instead of (−g, −f).
- Forgetting that a vertical line has an undefined (not zero) slope.
18
30-Second Revision Box
- Distance, midpoint, section and centroid formulas
- Slope m=(y2−y1)/(x2−x1); parallel m1=m2; perpendicular product=−1
- Line forms: slope-intercept, point-slope, two-point, intercept
- Point-to-line and line-to-line distance both use √(A²+B²) in the denominator
- Area of a triangle from coordinates; zero area means collinear
- Circle: centre (−g,−f), radius √(g²+f²−c)
